The production line is used to clean the storage tank used during the production and transportation of the electrolyte, effectively remove the polluted on the outer wall and residual stains on the inner wall, carry out the automatic pressure replacement storage, and monitor conductivity, pH and internal structure cleanliness of the tank in real time to guarantee the stable quality of subsequent electrolyte. The built-in RFID traceability system in the production line can control and trace the whole life cycle of the storage barrels. Besides recording the historical information of the barrels (including customer information, circulation time, storage type, standing time and filling type), it can also record the conductivity, pH and pressure holding value before and after cleaning at any time. The main structure is made of anti-rust and anti-corrosion materials, which has a long service life; All lines are equipped with active exhaust system to isolate operators from contact with high-risk substances; With the function of collection and treatment of waste liquid waste water, it can meet the environmental protection requirements; Monitor the cleaning effect dynamically, track and record the cleaning quality. The cleaning efficiency is increased by 400% compared with the traditional manual cleaning, while the manual demand is reduced by 70% and the water consumption is reduced by 50%. The intelligent storage system can, according to the program of the upper computer, classify the packaging barrels in an orderly manner, realize automatic access to the warehouse, and automatically dock with the filling line according to the DCS instruction. It effectively guarantees the cleaning effect, reduces the risk of quality control, reduces the production and environmental costs of enterprise, improves the intelligent degree of production and logistics, and increases the comprehensive benefits.

This automation line is used to clean the trays (flap box) used in the production of bare cells to eliminate the risk of particle contamination on the surface, so that they can be put back into production. The line body mainly includes feeding cache, opening displacement, Tray basketing, ultrasonic cleaning, clean compressed air purging, vacuum drying, automatic feeding and material basket back-flow and other functions, provided with RO water system and air purification system.

Mainly used for air tightness testing of battery packs in service sites and factories, the testing equipment can be used for small-scale product testing and batch battery pack testing applications. The main functions include the air tightness detection under high pressure and low pressure conditions, which can meet the detection requirements of different types of battery products. There is no need to switch hardware and the functions can beswitchedthrough software. In addition, it is equipped with a special standard tank for self-calibration.

This workstation is used to recycle the cathode materials adhered and corroded in the cathode material sagger of lithium ion battery. The cathode materials rich in cobalt, lithium, nickel and other metals are completely stripped through the flexible cleaning of the inner wall, outer wall, bottom surface and R angle of the sagger, and the by-products are collected for the subsequent fine recycling. While creating economic value, it can reduce the risk of leakage of process formula and transportation of dangerous waste due to the unclean cleaning after the sagger is eliminated.
